Face Milling Cutter
Face Milling Cutters from WDF are produced by a veteran China manufacturer and factory with years of industry experience. Skilled craftsmen and advanced equipment ensure each cutter meets strict quality standards from material selection to final inspection. As a trusted supplier, WDF delivers precise, durable, and reliable cutters with excellent service, making us the preferred choice for high-performance milling applications.
The WDF Quality face milling cutter is specifically designed for precision milling of cast iron surfaces. The cutter is specifically designed for cast iron, with a blade design that reduces cutting effort and prevents damage to the workpiece surface. The blade is meticulously crafted for stable rotation, and the blade is precisely positioned, ensuring accurate and smooth milling. Not only are our cutters strong, but our people are also reliable. From the moment you have an idea, our team will be with you every step of the way, helping you select the right model, resolving technical issues, and providing thorough after-sales service. If you encounter any problems with your cutter, we'll respond immediately and ensure a thorough solution, leaving you worry-free.
Product Parameters
|
Geometry |
Face Milling Cutter |
|
Structure |
Carbide (cutting edge) + 40Cr steel body (high rigidity) + shallow spiral chip flute (optimized cast iron chip removal) + precision shank connection (internal thread/tapered hole positioning) |
|
Type |
Metal cutting tool (specialized for high-precision surface milling of cast iron, focusing on finishing processes) |
|
Material |
Cutting edge: Ultra-fine-grained carbide (such as WC-Co alloy, coated with TiCN or AlTiN for enhanced wear and chipping resistance); Body: 40Cr alloy steel (quenched to a hardness of HRC 30-35, ensuring rigidity, stability, and reducing vibration) |
|
Processing Material |
Suitable for finish milling of medium- to high-hardness cast iron materials, such as gray cast iron (HT200/HT300) and ductile iron (QT450/QT600) |
|
Other Characteristics |
The cutting edge boasts exceptionally high precision (radial runout ≤ 0.005mm), achieving workpiece flatness of 0.01mm/100mm and a surface finish of Ra ≤ 0.4μm. The shallow spiral chip flute is ideal for brittle cast iron chips, preventing clogging. The tool supports medium- and high-speed cutting (linear speeds of 80-200m/min) for stable, chatter-free cutting. The tool body features balancing holes for optimized dynamic balancing, making it compatible with high-precision machining centers and ensuring long-term dimensional consistency. |
|
Diameter |
Minimum diameter: 40mm (small precision milling cutter, suitable for small flat surfaces); maximum diameter: 160mm (large precision milling cutter, suitable for large cast iron surfaces; customizable upon request). |
Product Features and Applications
1. The material coating is specially formulated for cast iron, providing a wear-resistant "coat" that withstands wear and tear, ensuring stable cast iron cutting and extended service life.
2. Milling results are precise and smooth, allowing you to mill cast iron surfaces with pinpoint accuracy and minimal roughness, meeting even the most demanding precision requirements.
3. Steady cutting with minimal defects. Working steadily and without shaking, the cutter produces fewer defects and consistently high quality.
4. It works quickly and without errors, enabling it to keep up with fast-paced finishing and handle batch jobs without interruption. And while it's fast, it's also precise, ensuring uncompromising accuracy. This is the ultimate in speed and quality. This Durable face milling cutter is primarily used for milling cast iron surfaces to a precise and smooth finish, and is used in a wide range of industries. Typical examples include automotive parts like engine cylinder heads, transmission cases, and brake discs; and machine tool guideways and worktables. It's also essential for precision milling in industries like construction machinery, hydraulic and pneumatic equipment, and train and subway systems.
